械規格 |
機型項目 |
JL-618SA |
JL-818 |
|
|
JL-2A618 |
JL- 818SA |
JL- 3060AH |
|
JL-3A618 |
JL-2A818 |
JL- 3060ATD |
|
JL-618ATD |
JL-3A818 |
JL-3060CNC |
|
JL-618CNC |
JL-818ATD |
|
|
|
JL-818CNC |
|
|
加工能力 |
工作台面積 (mm)(inch) |
150x465 |
200x465 |
300x648 |
|
(6"x18") |
(8"x18") |
(12"x25.5") |
|
工作台最大行程 (mm) (inch) |
175x472 |
205x472 |
380x680 |
|
(7"x18.8") |
(8"x18.8") |
(15"x27") |
|
最大研磨面積 (mm)(inch) |
150x450 |
200x450 |
300x600 |
|
(6"x18") |
(8"x18") |
(12"x24") |
|
工作台面至主軸中心最大距離 |
400mm(16") 450mm(18") |
600mm(24") |
|
左右 進給 |
工作台移動速度 |
3 ~ 25mm/min |
5 ~ 23mm/min |
|
(無段) |
(0.12" ~ 1"/min) |
(0.2" ~ 0.9"/min) |
|
前後 進給 |
自動進給 |
0.1mm ~ 5mm/min(2A) |
0.1mm ~ 5.5mm/min |
|
(0.004" ~ 0.5"/min) |
(0.004" ~ 0.22"/min) |
|
快速進給 (mm/min) |
1300(52")mm/min(2A) [60Hz] |
1400(56")mm/min [60Hz] |
|
1100(44")mm/min [50Hz] |
1200(48")mm/min [50Hz] |
|
手輪 |
5mm(0.1" ) |
|
1rev.(每轉) |
0.02mm(0.0005") |
|
1gra (每刻度) |
|
|
|
|
微調進給 |
0.1mm(0.002") [option] |
|
1rev.(每轉) |
0.002mm(0.00005") [option] |
|
1gra (每刻度) |
|
|
上下 進給 |
快速進給 |
180(7.2")mm/min(3A) [60Hz] |
AH 420(350)mm/ |
|
60Hz |
150(6")mm/min [50Hz] |
min(16.8")(14") |
|
50Hz |
|
ATD 280(230)mm/ |
|
|
|
min(11.2")(9.2") |
|
手輪 |
1mm(0.04") |
|
2mm(0.08") |
|
1rev.(每轉) |
0.005mm(0.0002") |
|
0.01mm(0.0004") |
|
1gra (每刻度) |
|
|
|
微調進給 (特殊規格) |
0.02mm(0.001") [option] |
|
|
0.001mm(0.00005") [option] |
|
自動進給 |
0.001mm / P,P.S(ATD) |
0.001mm / P,P.S(ATD) |
|
砂輪 |
主軸轉速60Hz/50Hz |
3500/2900R,P.M. |
|
1750/1450 R.P.M |
|
砂輪尺寸 mm (inch) |
180x13x31.75 (7.2"x0.5"x1.25") |
|
355x37.5x127 |
|
|
|
(14.2"x1.5"x5") |
|
馬達 |
主軸馬達 |
1.5HP x2P |
2HPx2P |
5HPx4P |
|
油壓馬達 |
1HPx6P |
2HPx6P |
|
前後馬達 |
5RK-40A-S(2A.3A)(ATD:DC 10SP) |
1/5HPx6P |
|
升降馬達 |
5RK-40A-S(3A),103-815-2(ATD) |
5RK-90A-S (AH), |
|
PK299-01A(ATD) |
|
冷卻泵浦 |
1/8HP |
|
|
|
重量 |
機器淨重 Kgs (Lbs) |
750 |
850 |
2000 |
|
(1650 Lbs) |
(1870 Lbs) |
(4400 Lbs) |
|
裝箱毛重 Kgs (Lbs) |
900 |
1000 |
2300 |
|
(1980Lbs) |
(2200 Lbs) |
(5060 Lbs) |
|
尺寸 |
機器作業空間mm(inch) |
1950x1200 |
1950x1200 |
2600x2050 |
|
(78"x48") |
(78"x48") |
(104"x82") |
|
包裝尺寸 |
200x106x210 |
195x106x210 |
224x196x210 |
|
(長x高x寬) |
ATD(224x133x210) |
ATD(224x133x210) |
(90"x78"x84" |
|
cm (inch) |
(90"x53"x84") |
(90"x53"x84") |
|
|
|
|
|
|
